Ageing Room

Product Description

Ageing Room

Standard size in mm           :   300 x 300 x 300mm / 450 x 450 x 450mm / 600 x 600 x 600mm.
Temperature range             :   5^oC above ambient to 100 deg C / 200 deg C / 300 ^deg C.

Temperature Controller:

1. Digital temperature indicator cum controller with 0.1 deg C display resolution.
2. Temperature controlling accuracy: -/+ 1 deg C up to 200 deg C.
3. Display accuracy -/+ 0.5%, full scale.
4. Sensor: PT100, Class-A type.

Construction:

1. Inner chamber made of Stainless steel 304 grade, duly polished.
2. Outer made of Mild Steel with powder coated.
3. Air heater.
4. Glass wool insulation.
5. Forced air circulation provided to maintain temperature uniformity.
6. Asbestos gasket, lock and handle for door.
7. SS meshed trays.

Power Supply:

1. Single phase 230V, 50Hz.

Optional:

1. Fully Stainless steel (Inner and Outer)

Note: Due to continuous development SSLI reserves the rights to change specifications without prior notice.
