Industrial Humidity Chamber Manufacturer from India

About Industrial Humidity Chamber Manufacturer from India

Humidity Test Chambers

Leveraging on our experience, we are engaged in offering Humidity Test Chambers. These chambers are manufactured from superior grade components sourced from reliable vendors of the market as per the set industry norms. The entire range of Humidity Test Chambers is highly admired for smooth operation, high strength, low running cost and longer functional life. The offered chambers are available in different capacities to meet the diverse needs of the clients.

Humidity Chamber

• Standard sizes : 600mm x 600mm x 600mm, 750mm x 750mm x 750mm, 1000mm x 1000mm x 1000mm
• Temperature range : 10oC to 60oC
• Humidity range : 40% to 98% Rh @ (30oC to 80oC).

Technical Specifications:

• Temperature cum Humidity Controller (dry and wet bulb method)
• Digital Microprocessor based, PID, Temperature Indicator cum controller with display resolution of 0.1oC.
• Digital Microprocessor based, PID, Humidity Indicator cum controller with display resolution of 1%Rh. (direct reading).
• Temperature controlling accuracy +2oC.
• Humidity controlling accuracy of +2 - 3% @ 40% to 98% Rh.
• Display accuracy +0.5%, full scale.
• Class A grade, PT-100 Sensor (RTD)

Construction:

• Vertical model.
• Inner Chamber made of dully polished Stainless Steel, 304 Grade, Outer made of Mild Steel, powder coated.
• Polyurethane Foam Insulation (PUF).
• Handle, lock and heavy-duty hinges for door.
• Door with Neoprene rubber gasket for leak proof.
• Forced air circulation to maintain uniformity of temperature.
• Frost Free Viewing Window to observe the testing components during working condition.
• Double walled full front opening door. Inner lined with SS.
• Long life Ni-chrome, SS heaters with fins for higher temperature.
• Automatic cut off for circulating fan when the door is opened
• Lockable Wheels for easy movement.
• Drain facility is provided to collect water, which is produced during humidity testing condition.
• Adjustable SS meshed trays.

Refrigeration System:

• Single stage with hermetically sealed EMERSON Copeland make compressor.
• CFC free refrigerant filled.
• Fin and tube type air-cooled condenser.
